Name: رله نظامی 010-1069-974 - فروشگاه تخصصی الکترونیک و ابزار
SKU: 6989794
Price: 12530414 IRT
Availability: InStock

توضیحات

MRC	Criteria	Characteristic
ABHP	OVERALL LENGTH	1.344 INCHES NOMINAL
ABKQ	CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH	1.062 INCHES NOMINAL SINGLE MOUNTING FACILITY
ABKW	OVERALL HEIGHT	1.000 INCHES NOMINAL
ABMK	OVERALL WIDTH	0.406 INCHES NOMINAL
ADZC	ENVIRONMENTAL PROTECTION	HERMETIC
AEBV	UNTHREADED MOUNTING HOLE DIAMETER	0.109 INCHES NOMINAL SINGLE MOUNTING FACILITY
AKDX	WINDING QUANTITY	1
APCN	COIL QUANTITY	1
APNA	WINDING DC RESISTANCE RATING	10.0 KILOHMS NOMINAL SINGLE WINDING
APNP	DUTY TYPE	CONTINUOUS
AXHR	MOUNTING FACILITY TYPE AND QUANTITY	2 UNTHREADED HOLE SINGLE MOUNTING FACILITY
AYSC	PILE-UP MAIN CONTACT FORM ARRANGEMENT	2C
CQYJ	MOUNTING FACILITY PATTERN	IN-LINE SINGLE MOUNTING FACILITY
CRNG	NONPILE-UP MAIN CONTACT ARRANGEMENT	2 POLE
CRPQ	NOMINAL OPERATING CURRENT RATING AND TYPE	5.0 MILLIAMPERES DC SINGLE WINDING
CSXF	OPERATING VOLTAGE RATING AND TYPE AT SPECIFIED TEMP	28.0 VOLTS DC 25 DEG CELSIUS SINGLE WINDING
CTDL	MAIN CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE	1.0 AMPERES AC RESISTIVE LOAD AND 1.0 AMPERES DC RESISTIVE LOAD
CWAB	MAIN CONTACT MAXIMUM VOLTAGE RATING IN VOLTS	115.0 AC AND 28.0 DC
TTQY	TERMINAL TYPE AND QUANTITY	8 WIRE HOOK ALL FUNCTIONS

اطلاعات بیشتر

وزن	100 گرم
